LABORATORY INFORMATION:-

1. Name of Laboratory Fluid Power
2. Area of Laboratory 80.00 sqm
3. Laboratory Incharge Prof. A. A. JYAPPA
4. Laboratory Assistant P. I. PATIL
5. Laboratory Investment Rs. 191613/-
6. Laboratory Photograph
7. List of Major Equipments
  1. Basic peneumatic trainer kit(orderning code JTK7)
  2. Hydralic trainer kit.
  3. Demonstration of shaper machine
1. Name of Laboratory Metrology & Quality Control Lab
2. Area of Laboratory 80.00 sqm
3. Laboratory Incharge PROF. V. V. SALUNKHE
4. Laboratory Assistant K. K. ZENDE
5. Laboratory Investment Rs. 500644/-
6. Laboratory Photograph
7. List of Major Equipments
  1. C.I.Surface Plate
  2. Set of Slip Gauge (83 pieces)
  3. Radius Gauge with different radius
  4. Feeler Gauge
  5. Screw Pitch Gauge
  6. Monochromatic Light Source with specimen
  7. Sprit Level Block
  8. Vee Block 90 degree
  9. Vernier Calliper 0-150mm. L.C. 0.01mm
  10. Depth Micrometer 0-25mm. L.C. 0.01mm
  11. Vernier Height Gauge 0-300mm with magnifying glass
  12. Dial Indicator
  13. Vernier Bevel Protector
  14. Sine Bar 100 mm
  15. Sine bar 200 mm
  16. Set of Angle Gauges in Deg., Min., Sec.,
  17. Screw Thread Micrometer
  18. Adjustable Snap Gauge 0.6 mm
1. Name of Laboratory Power Engg Lab
2. Area of Laboratory 80.00 sqm
3. Laboratory Incharge PROF. A. A. JAYAPPA
4. Laboratory Assistant P. I. PATIL
5. Laboratory Investment Rs. 207862/-
6. Laboratory Photograph
7. List of Major Equipments
  1. Rotary cut compressor
  2. Hermatically sealed compressor
  3. Rotary cut section compressor
  4. window AC Demonstrartive
  5. Types of gasket
  6. Cylinder head gasket
  7. Two stage air compressor test rig
  8. Water cooler test rig
  9. Ice plant test rig
  10. working windo A/C
  11. Hermatically sealed compressor
  12. Refrigeration trainer
  13. Rotary compressor(cut section)
1. Name of Laboratory ENERGY LAB
2. Area of Laboratory 75.00 sqm
3. Laboratory Incharge PROF. V. V. SALUNKHE
4. Laboratory Assistant K. K. ZENDE
5. Laboratory Investment Rs. 53368/-
6. Laboratory Photograph
7. List of Major Equipments
  1. Solar cooker
  2. Horizontal axis wind turbine
  3. Transparent glass wall
  4. Solar and windmill hybrid power plant
  5. Vertical axix wind turbine
  6. Biomass Gasifier power system unit demo
  7. Solar PV cell unit
  8. Solar water heater
  9. Digital Clamp Meter
1. Name of Laboratory Theory of Machines
2. Area of Laboratory 75.00 sqm
3. Laboratory Incharge PROF. R. B. SONAWANE
4. Laboratory Assistant K. K. ZENDE
5. Laboratory Investment Rs. 71987/-
6. Laboratory Photograph
7. List of Major Equipments
  1. Geneva Mechanism
  2. Foot operated air pump mechanism
  3. Rotary I.C.Engine Mechanism
  4. Bicycle Freewheel and sprocket mechanism
  5. Skotch Yoke Mechanism
  6. Double slider crank mechanism-Elliptical Trammel
  7. Ackermans Steering gear mecahanism
  8. motorised governer appratus
  9. Single slider chain mechanism-Reciprocating cylinder mechanism
  10. Band and block brake system
  11. Internal expanding brake system
  12. Band brake
  13. Single shoe brake system
  14. Models of cam and followers
  15. Types of kinematic pair
  16. Kinematic link model
  17. Types of belts
  18. Chain wheel drive
  19. Belt drive
  20. Different type of gears
  21. Single plate clutch- Static model
  22. Multiplate Clutch Static model



1. Name of Laboratory FLUID MECHANICS & MACHINERY
2. Area of Laboratory 75.00 sqm
3. Laboratory Incharge PROF.  K. D. TAMBE
4. Laboratory Assistant K. K. ZENDE
5. Laboratory Investment Rs. 218042/-
6. Laboratory Photograph
7. List of Major Equipments

  1. Calibration of bourden pressure guage with the help of de



  2. Verification of Bernoullis theorem appratus

  3. Reciprocating pump testrig

  4. Centrifugal pump testrig

  5. Hydraullic Bench Setup for minor losses in pipe

  6. Orifice Plate testrig

  7. Pitot Tube

  8. Differential Manometer

  9. Simple Manometer

  10. Pelton wheel turbine test rig.

  11. Pipe friction appratus

  12. Determination of coefficient of discrge by venturimeter and orificemeter
